PART 7: STARTING & OPERATING THE VEHICLE BRAKE SAFETY AND EMERGENCY
(R10/06) Y53-6007 – 103 –
3. Slide out the release stud
4. Insert the release stud through the opening in the
spring chamber where the cap was removed. Insert it
into the pressure plate. Turn the release stud 1/4-turn
clockwise in the pressure plate. This secures the
cross pin into the cross pin area of the pressure plate
and locks it into the manual release position.
02936C
02937A
