STEP 2
Prepare the Receiver Collar
To Insert and Remove the Batteries
1. Remove the screws with a small Phillips screwdriver, applying
adequate pressure for the screwdriver head to  t snugly into
thescrew (2A).
2. Push the Battery Lid up according to the arrows stamped on the
Battery Lid (2A).
3. Slide the Battery Lid out.
4. Install two (2), 3-volt batteries positive (+) side up (2B). Slide the
Battery Lid into the Receiver Collar.
5. Reinstall the screws (2B). Do not over-tighten the screws.
The Receiver Collar is waterproof. When changing the batteries, be
sure to keep the area free of dirt and debris. Also, ensure the screws
are  ush with the Battery Lid. Replacement batteries (3-volt, CR2032)
can be found at many retailers. Contact the Customer Care Centre or
visit our website at www.petsafe.net for a list of common retailers.
TO REMOVE
SLIDE THEN LIFT
TO REMOVE
SLIDE THEN LIFT
2A
Batteries
(CR2032)
2B
