CATALYTIC EXHAUST
Composition of the catalytic exhaust system:
The catalytic exhaust system is distinguished by the fitting of a « catalyser cone » just after the exhaust
inlet cone. All the exhaust gases are fed through the catalyser cone.
1. Exhaust pipe
2. Heat insulation
3. Catalyser cone
FUNCTIONING OF THE CATALYTIC CONVERTER EXHAUST
Definition
The catalyser is a block used to facilitate and acceleration chemical reactions without being modified
itself
Composition of the catalytic block
The catalytic block is composed of a metal grid, impregnated with precious metals, rolled inside a steel
tube forming a honeycomb.
1. Metal grid
2. Steel tube
3. Honeycomb
4. Impregnation with precious metals (Platinum, palladium, rhodium, etc...)
