8 - 5
Mounting and commissioning the machine
8.04 Basic setting of the machine drive unit
● Switch on the machine.
● Press TE/Speed key twice to call up the input mode.
2 x
● By pressing the corresponding +/- key, call up parameter "798" and select service level
"C", see Chapter 12.07.01 Selecting the user level.
● By pressing the corresponding +/- key, call up parameter "800" (rotation direction of the
motor).
● By pressing the corresponding +/- key, set the value at "1".
TE
101 on
ABCD
3333
TE
798 11
C
A
● By pressing the corresponding +/- key, call up parameter "700".
TE
800 1
C
