12
● Set the stitch length at “0” and position the needle right above the needle hole.
● Loosen screws 1 and 2.
● Position needle bar frame 3 both lengthwise and crosswise of the sewing direction
according to the requirement and tighten screw 1.
● Turn the handwheel a few turns to ensure that the needle bar is not under stress in the
needle bar frame and tighten screw 2.
8 Centering the needle in the needle hole
Requirement
The needle must penetrate the needle hole right in the center.
3
2
1
8.1 For PFAFF 481
