Pfaff 481 Service Manual

27
22 Limiting the stitch length
● Loosen screw 1 (accessible through the assembly hole) or turn it out according to the limit
to be set.
● Set stitch length control lever 2 at the desired maximum stitch length.
● Set limiting angle 3 from above against control lever 2 and fix it (in the desired position) by
tightening screw 1 in either the lower or the upper hole.
2
1
3
