Installation and commissioning
8 - 7
8.02.05 Connecting the safety switch
● Connect plug 1 of safety switch 2 as
shown in Fig. 8-12.
When the sewing head is tilted
back, the safety switch
prevents the machine starting
when the main switch is on.
To deactivate the safety switch,
the main switch must be
switched off and then on again
after the machine has been
brought to an upright position.
61-113
Fig. 8 - 12
1
2
58.011
8.03 Connecting the earth cable
● Screw the earth cable from the sewing
head, motor, main switch and work aids
to the stand.
Fig. 8 - 13
