Adjustment
11 - 1
11 Adjustment
11
.01 Notes on adjustment
All following adjustments are based on a fully assembled machine and may only be carried
out by expert staff trained for this purpose.
Machine covers, which have to be removed and replaced to carry out checks and
adjustments, are not mentioned in the text.
The order of the following chapters corresponds to the most logical work sequence for
machines which have to be completely adjusted. If only specific individual work steps are
carried out, both the preceding and following chapters must be observed.
Screws, nuts indicated in brackets ( ) are fastenings for machine parts, which must be
loosened before adjustment and tightened again afterwards.
The machine must be switched off for all adjustment work!
Danger of injury if the machine is started accidentally!
11.02 Tools, gauges and other accessories
● 1 set of screwdrivers with blade widths from 2 to 10 mm
● 1 set of open-ended wrenches with opening sizes from 7 to 13 mm
● 1 set of allen keys from 1.5 to 6 mm
● 1 clamp (Order No. 08-880 137-00)
● 1 metal rule (Order No. 08-880 218-00)
● 1 gauge (Order No. 08-880 136-01)
● Sewing thread and test material
11.03 Abbreviations
TDC = top dead center
BDC = bottom dead center
