6:2
Changing the needle plate
Switch off the main switch.
Removal
• Raise the presser foot. Position the needle plate changer
(lamp changer) as shown and press the needle plate up on
the right, then on the left. It can now be easily removed.
Replacing
• Place the needle plate against the rear edge of the cut-out
then press down at the front until you hear it snap in place.
Before you start sewing, check that the needle plate is lying
fl at.
Tip: Lower the feed dogs to make removing the needle plate easier.
Cleaning
Switch off the main switch.
• Remove the needle plate and lower the feed dogs. Clean the
feed dogs and hook area with the brush.
• Clean the sewing machine after every 10 - 15 hours of opera-
tion.
Cleaning the window
Wipe the window with a soft, lint-free dry cloth. DO NOT use
abrasive cleansers or solvents!
