Pfaff hobby 1142 Service Manual

A
A
A
A
A
A
C
B
B
A
C
104 72 62-26 5
Face plate
Face cover:
1. Remove cap (A).
2. Unscrew screw (B) of the face cover.
3. Remove face cover (C) .
Removing the housing covers
1. Remove the six set screws (A)
2. Remove the base cover (B).
To attach
Shift the drop feed lever (C) in the direction of the arrow.
Attach the base cover with setscrews.
Base cover

Pfaff hobby 1142 Specifications

General

Buttonhole	1-step
Stitch Width	5 mm
Stitch Length	4 mm
Needle Positions	Variable
Free Arm	Yes
Needle Threader	No
Drop Feed	Yes
Type	Mechanical
Number of Stitches	23
Bobbin Type	Front loading
Presser Feet Included	Standard foot, Zipper foot, Buttonhole foot
