Pfaff powerline 2235 - Top-Feed Lifting Motion

16
Adjustment
1.05.11 Top-feed lifting motion
Requirement
The top feed dog should just have reached the needle plate when the presser foot lift is
set at 5 mm and the needle descending from above is 2 mm above the needle plate.
Turn eccentric ● 1 (screw 2) in accordance with the requirement.
2 mm
1
2
Fig. 1 - 11
