Pfaff powerline 2235 - Bobbin Winder

18
Adjustment
1.05.13 Bobbin winder
Requirement
When the bobbin winder is engaged, the winding spindle must be driven reliably. 1.
When it is disengaged, friction wheel 3 should not be touching drive wheel 1.
When it is switched off, the bobbin winder must click securely into its end position 2.
(knife raised).
Adjust drive wheel ● 1 (screw 2) in accordance with the requirement.
Fig. 1 - 12
2
1
3
