Pfaff Powerline 2545 - Controls; On;Off Switch; Sewing Lamp Switch

16
Controls
7 Controls
7
.01 On/off switch
Fig. 7 - 01a
2
Fig. 7 - 01
1
Machines with motor PF 321
● Operate main switch 2 to switch the
machine on or off.
Machines with motor P45 PD2-L + P74 ED-L
● The power supply to the machine is swit-
ched on or off by turning switch 1.
7.02 Sewing lamp switch (only on the PFAFF 2545 / 2546 CLASSIC and PLUS)
● Switch the sewing lamp, which is inte-
grated in the machine head, on or off by
operating switch 1.
Fig. 7 - 01b
1
