5 Operation
Important settings and function-related variables are programmed ex factory as parameters in the vac-
uum pump electronic drive unit. Each parameter has a three-digit number and a description. Parameter-
driven operation and control is supported via Pfeiffer Vacuum displays and control units, or externally
via RS-485 using Pfeiffer Vacuum protocol.
Parameter Name Designation Adjustment/comment
[P:035] CfgAccA1 Accessory connection A1 0 = fan (continuous operation)
4 = fan (temperature controlled)
[P:330] TempPmpBot Pump lower part temperature Factory setting for respective pump,
for status requests only (readable)
[P:342] TempBearng Bearing temperature
Tbl. 5: Parameter settings in the electronic drive unit of the turbopump
Information regarding commissioning of the turbopump with air cooling
►
Continuous operation: The fan runs in continuous operation as soon as voltage is supplied.
►
Temperature controlled: The fan runs according to the switch point settings ex factory.
Operation
