Sequence of multi-part action steps
The numerical list indicates an action with multiple necessary steps.
1. Step 1
2. Step 2
3. ...
1.3.2 Pictographs
Pictographs used in the document indicate useful information.
Note
Tip
1.3.3 Stickers on the product
This section describes all the stickers on the product along with their meaning.
Mod.: Air cooling
Mod.-Nr.: PM Z01 302 A
D-35641 Asslar
Made in Germany
Input: 24 V/DC
12/2019
Rating plate (example)
The rating plate is located on the fan housing
Tbl. 3: Stickers on the product
Fig. 1: Position of the sticker on the product
1 Rating plate
About this manual
7/26
