7 Technical data and dimensions
7.1 Technical data
Classification Air Cooling Air Cooling Air Cooling
Part number PM Z01 300 PM Z01 301 PM Z01 348
Pump HiPace 60 | HiPace 80 | Split-
Flow 50/80
HiPace 300/450 HiPace 30
Electronic drive unit TC 110, TC 120, TCP 350 TC 110, TC 120,
TCP 350
TC 110, TC 120
Control voltage 24 V DC 24 V DC 24 V DC
Electrical connection M8 M8 M8
Tbl. 6: Air cooling with M8 connecting thread unshielded, 24 V DC
Classification Air Cooling, shield-
ed
Air cooling, shielded Air cooling, shielded
Part number PM Z01 373 PM Z01 360 PM Z01 361
Pump HiPace® 350/450 SplitFlow 50/80, Hi-
Pace 60P, HiPace 80
HiPace 300
Electronic drive unit TC 110, TC 120 TC 110, TC 120, TCP 350 TC 110, TC 120,
TCP 350
Control voltage 24 V DC 24 V DC 24 V DC
Electrical connection M8 M8 M8
Tbl. 7: Air cooling with M8 connecting thread shielded, 24 V DC
Classifica-
tion
Air Cooling Air Cooling Air cooling,
shielded
Air cooling,
shielded
Air Cool-
ling, shield-
ed
Part num-
ber
PM Z01 302 PM Z01 303 PM Z01 362 PM Z01 363 PM Z01 374
Pump HiPace 300 HiPace
400/700/800
HiPace 300 HiPace
400/700/800 | Hi-
Pace 300 M/
700 M/800 M
HiPace®
350/450
Electronic
drive unit
TC 400,
TCP 350
TC 400,
TCP 350
TC 400 PB,
TCP 350
TC 400 PB,
TCP 350, TM 700
TC 400,
TCP 350
Control
voltage
24 V DC 24 V DC 24 V DC 24 V DC 24 V DC
Electrical
connection
M12 M12 M12 M12 M12
Tbl. 8: Air coolings with M12 connecting thread, 24 V DC
Classification Air Cooling Air Cooling Air Cooling Air Cooling
Part number PM Z01 308 PM Z01 309 PM Z01 342 PM Z01 341
Pump HiPace 300 HiPace 300 HiPace 400/700/800 HiPace 400/700/800
Mains connection: Volt-
age
115 V 230 V 115 V 230 V
Tbl. 9: Air coolings 115/230 V/AC
