18
The Pfeiffer Vacuum parameter set
6.2.5 Set value settings
6.3 Configuring the connections
The electronic drive unit is pre-configured in the factory. Thereby the turbopump is im-
mediately operational with the necessary functions. The connections of the electronic
drive unit can be configured to suit individual requirements using the parameter set.
6.3.1 Digital outputs on "X3"
 Configuration via parameters [P:019] and [P:024].
369 ErrHist10 Error code history, pos. 10 4 R x
397 SetRotSpd Set rotation speed (rpm) 1 R rpm 0 999999
398 ActualSpd Actual rotation speed (rpm) 1 R rpm 0 999999
399 NominalSpd Nominal rotation speed (rpm) 1 R rpm 0 999999
# Display Designation Functions
Data type Access
Unit min max default 
# Display Designation Functions
Data type Access method
Unit min max default 
700 RUTimeSVal Set value run-up time 1 RW min 1 120 8 x
701 SpdSwPt1 Rotation speed switchpoint 1 1 RW % 50 97 80 x
707 SpdSVal Set value in rot. speed setting mode 2 RW % 20 100 65 x
708 PwrSVal Set value power consumption 7 RW % 10 100
100
1
x
710 Swoff BKP Switching off threshold backing pump in intermit-
tend mode
1 RW W 0 1000 0 x
711 SwOn BKP Switching on threshold backing pump in intermit-
tend mode
1 RW W 0 1000 0 x
717 StdbySVal Set value rotation speed at standby 2 RW % 20 100 66.7 x
719 SpdSwPt2 Rotation speed switchpoint 2 1 RW % 5 97 20 x
720 VentSpd Venting rot. speed at delayed venting 7 RW % 40 98 50 x
721 VentTime Venting time at delayed venting 1 RW s 6 3600 3600 x
730 PrsSwPt 1 Pressure switchpoint 1 10 RW hPa x
732 PrsSwPt 2 Pressure switchpoint 2 10 RW hPa x
739 PrsSn1Name Name sensor 1 4R
740 Pressure 1 Pressure value 1 10 RW hPa x
742 PrsCorrPi 1 Correction factor 1 2RW x
749 PrsSn2Name Name sensor 2 4R
750 Pressure 2 Pressure value 2 10 RW hPa x
752 PrsCorrPi 2 Correction factor 2 2RW x
777 NomSpdConf Nominal rotation speed confirmation 1 RW Hz 0 1500 0 x
797 RS485Adr RS-485 device address 1 RW 1 255 1 x
1. depending on the pump type
Option Description
0 = Rotation speed switchpoint attained Active, if switchpoint attained
1 = No error Active, if failure-free operation
2 = Error Active, if error message is active
3 = Warning Active, if warning message is active
4 = Error and / or warning Active, if error and / or warning is active
5 = Set rotation speed attained Active, if set rotation speed is attained
6 = Pump on Active, if Pumping station and Motor is on; No Error
7 = Pump accelerates Active, if Pumping station is on;
Actual rotation speed < Set rotation speed
8 = Pump decelerates Active, if Pumping station is on;
Actual rotation speed > Set rotation speed
Pumping station is off;
Rotation speed > 3 Hz
9 = always 0 GND for the control of an external device
10 = always 1 +24 V DC for the control of an external device
11 = Remote priority active Active, if Remote priority is active
12 = Heating Control is equal to parameter [P:001]
13 = Backing pump Control is equal to parameter [P:010] and [P:025]
