PFT G 54 E - Component Overviews

PFT G 54 E Operating Instructions 09/2006
Knauf PFT GmbH & Co.KG
10
Overview of the G 54 E, item number: 00 05 69 13
1. Motor connection cable 2. Mixer pump motor
3. Protection grille / material hopper 4. Material hopper
5. Tool box 6. High pressure pump
7. Water supply 8. Compressor
9. Mortar pressure gauge 10. Pump system
11. Water inlet / mixing tube 12. Control box
13. Locking lever / mixing tube 14. Mixing tube
