PFT G 54 E - Overview of the Control Box, Item Number: 00 02 13 43

PFT G 54 E Operating Instructions 09/2006
Knauf PFT GmbH & Co.KG
11
Overview of the control box, item number: 00 02 13 43
1. Red “fault” control lamp 2. Orange “change direction of rotation” control
lamp
3. Main reversing switch 4. Water pump socket, 16 A
5. Compressor socket, 16 A 6. 230 V earthling outlet, 16 A fuse
7. Mixer pump motor socket 8. Blind plug, 4-pin, HAN 3A
9. Mains connection, 32 A 10. 4-pin remote control plug
11. Star wheel selector switch 12. Operation ON
13. Operation OFF 14. Water flow button
15. Pump motor reverse pressure switch (blue)
