PFT G 54 E Operating Instructions 09/2006
Knauf PFT GmbH & Co.KG
18
Connect the compressor.
Connect the water pump.
Connect the control box to the power supply.
Turn on the main switch.
Warning!
The protective grille may not be removed while
preparing or operating the machine.
Press the green “ON” pressure switch (1).
Press the water flow button (2) (water pump runs).
Adjust the water factor
Adjust the expected water volume at the needle valve (3). Observe the
specifications of the material manufacturer.
During operation: Every interruption of the spraying procedure results in
minor irregularities of the mortar consistency, which normalise, however, as
soon as the machine has been working for a while. So do not change the
water quantity each time you detect irregularities, but instead wait until the
consistency of the mortar emerging at the spraying gun has self-adjusted.
1
2
3
