Spraying gun
Connect the spraying gun (finishing coat gun or crimp valve gun) to the
mortar hose.
Press the green “ON” pressure switch (1) and open the air tap on the
spraying gun.
The machine starts; cleaning can now be started.
A
t first material of low consistency flows out of the spraying gun, then
mortar of the correct consistency. If necessary, adjustments can be made
with the needle valve.
The machine can now be switched on and off by opening and closing the
air tap (2, top figure) on the spraying gun.
1
2
