PG DRIVES TECHNOLOGY AC TRACTION – CALIBRATION
1 Calibration
Ref. Parameter Programmer Text
7.1 Load Defaults LoadDefs
7.2 Offset 1 M1 Ofset 1 +
7.3 Offset 2 M2 Ofset 2 +
7.4 Offset 3 M3 Ofset 3 +
7.5 Gain 1 M1 Gain 1
7.6 Gain 2 M2 Gain 2
7.7 Gain 3 M3 Gain 3
1.1 Load Defaults – (LoadDefs)
There are two programmable options – 0 and 1.
If set to 0, the Sigmadrive will not restore defaults the next time the power is cycled.
If set to 1, the Sigmadrive will restore all adjustments and authorization codes to their default values the next time the power is
cycled. It will also issue a warning error code ‘8’ to indicate that all defaults have been restored.
The default value of this parameter is ‘0’.
The Offset and Gain parameters are excluded from the default settings.
This option is not available on ‘Standard’ Programmers.
Care should be taken when utilizing this option. The motor set-up parameters, for example, will
contain default values, which might be out of range for the motor used. This could cause damage
to the controller and/or motors. PGDT accepts no liability for losses of any kind arising from
failure to comply with this condition.
1.2 – 1.7 Offset and Gain Settings.
These parameters are factory settings and should not be altered under any circumstances.
SK79646-01 83
