AC TRACTION – TECHNICAL SPECIFICATIONS PG DRIVES TECHNOLOGY
SK79646-01 94
3 Mechanical
Dimensions: Refer to frame drawings in Installation chapter.
Enclosure: Aluminium heatsink with ABS plastic cover.
Recommended fixing torques: Large and Medium frame – 11Nm Small frame – 9Nm.
Maximum screw thread penetration depth: All frame sizes – 14mm.
Weight: Small: 1.2Kg; Medium: 4.1Kg; Large: 6.1Kg.
Always use a torque screwdriver when fixing the power terminals.
Exceeding the maximum specified torque can cause serious damage to the controller and
warranty may be void.
Screws that are too long will damage the controller.
