Phanteks ECLIPSE P350X - Panel Removal Procedures; Left Side Panel Removal; Right Side Panel Removal; Front Panel Removal

PANEL REMOVAL
1. 1.
1.
2.
2.
1. 1.
1.
2.
2.
REMOVE THUMB SCREWS
REMOVE FRONT PANEL BY PULLING ON
THE PANEL FROM BELOW
LOOSEN THUMB SCREWS
SLIDE SIDE PANEL OFF
REMOVE TEMPERED GLASS PANEL
There are three panels which can be removed from the P350X and P360X Chassis; the left side
tempered glass panel, the right side panel and the front panel. Follow these steps below.
4x
REMOVE:
2x
LOOSEN:
LEFT SIDE PANEL
FRONT PANEL
RIGHT SIDE PANEL
Instructions for:
Eclipse P350X / Eclipse P360X
ECLIPSE P350X / P360X
INSTALLATION GUIDE V1.0
