8
SHIFT 2
SHIFT 2 air
GETTING STARTED
8x
LOOSEN:
PRESS THE TOP GRILL TO OPEN IT
LOOSEN ALL THUMB SCREWS
1.
2.
SLIDE THE PANELS UP
TAKE THE PANELS OUT
3.
4.
2
3
3
4
4
To remove or mount the rear panel the top grill must
be closed.
