Phanteks EVOLV SHIFT 2 User Manual

9
SHIFT 2
SHIFT 2 air
INSTALLING THE BOTTOM FAN
LAY THE EVOLV SHIFT 2 ON ITS SIDE
1.
PULL OFF THE BOTTOM GRILL
2.
INSTALL THE FAN WITH 4X FAN SCREWS
3.
PRE-ROUTE THE FAN CABLE OUTSIDE THE CHASSIS
4.
PUT THE BOTTOM GRILL BACK ON THE CHASSIS
5.
2
3
5
4
4
If you want to install a bottom fan we recommend to do it rst before proceeding
with the installation process.
4x
REQUIRES:

Phanteks EVOLV SHIFT 2 Specifications

General

GPU Length Support	Up to 335 mm
PSU Support	SFX, SFX-L
PCI Slots	2
Form Factor	Mini ITX
Material	Steel, Aluminum
Maximum CPU Cooler Height	85 mm
Radiator Support	Up to 120mm
Color Options	Black
