Table 6 – 480 V PTE Models and Ratings
Model
Power
(HP)
Output
(kVA)
Max Steady
State Output
Current (AAC)
Input
Voltage
Range
(VAC)
Max AC
Input
Current
(A)
Standby
Power/Energy,
(W/BTU/hr)
Full Load
Energy
Loss
(BTU/hr)
PTE407
PTE407QT
7.5
10.8
13
440-520
22
52/177
479
PTE410
PTE410QT
10
14.9
18
32
68/232
661
PTE415QT
15
22.4
27
48
71/242
994
PTE420QT
20
26.6
32
55
74/252
1180
Mechanical Specifications
Table 7 – 240 V PT Models – Enclosure Specifications
Models
PT007
PT010
PT020
PT030
PT040
PT050
PT060
PT075
Dimensions
Indoor: NEMA 1
(H x W x D)*
36 15/16” x 25 3/8” x 17 1/16”
44 15/16” x 25 13/16” x 19”
Dimensions
Outdoor: NEMA 3R
(H x W x D)*
37 7/16” x 25 3/8” x 19 5/16”
46 1/8” x 25 13/16” x 20 1/8”
Weight (lbs)
102
104
129
222
233
251
255
288
Table 8 – 240 V PTE Models – Enclosure Specifications
Models
PTE007
PTE007QT
PTE010
PTE010QT
PTE015
PTE020
Dimensions
Outdoor: NEMA 3R
(H x W x D)*
25 1/16" x 22 5/8"
x 7 15/16"
35 1/16" x 21 5/8"
x 7 15/16"
25 1/16" x
22 5/8" x
7 15/16"
35 1/16" x 21 5/8" x 7 15/16"
Weight (lbs)
51
60
51
65
71
72
Table 9 – Voltage Doubling PTE Models – Enclosure Specifications
Models
PTE207
PTE210
PTE015
PTE020
Dimensions
Outdoor: NEMA 3R
(H x W x D)*
35 1/16" x 21 5/8" x 7 15/16"
Weight (lbs)
