Startup Delay
WARNING! Risk of electric shock. De-energize the unit by disconnecting all incoming
sources of power, then wait 30 minutes for internal charges to dissipate before servicing
the equipment.
Startup Delay will force the converter to wait for a set time period before starting up. This
procedure will require wiring two ON/OFF switches to the converter. Standard light
switches will work. See Figure 25 for wiring diagram. To add a startup delay, follow the
steps below:
Step
Action
1
Turn power to PT OFF
2
Remove jumper wire between AUX1
and COM
3
Wire dry contact switch between AUX3
and COM (now called SW3)
4
Wire dry contact switch between AUX4
and COM (now called SW4)
5
Turn power to the PT ON
6
Toggle SW4 until you see STARTUP
DLY 4/5 on screen
7
Toggle SW3 to select between YES or
NO
8
Wait several seconds to allow this
programming to be saved
9
Repeat steps 6 and 7
10
SW3 ON to access STARTUP DLY
11
SW4 ON to access DLY TIME
Switches now act as toggle to select the STARTUP DELAY TIME.
Action
Effect
Toggle SW3
Decrease delay time
Toggle SW4
Increase delay time
Wait several seconds until “Programmed Successfully” is shown on the display, and then
return switches to the OFF position. Turn power to converter OFF, re-install jumper wire
between AUX1 and COM, then reapply power to converter.
