28 | Page
V2.1
Infinite Restarts
WARNING! Risk of electric shock. De-energize the unit by disconnecting all incoming
sources of power, then wait 30 minutes for internal charges to dissipate before servicing
the equipment.
Infinite Restarts will allow the converter to restart an unlimited number of times after fault
conditions. This procedure will require wiring two ON/OFF switches to the converter.
Standard light switches will work. See Figure 25 for wiring diagram. To add a startup delay,
follow the steps below:
Remove jumper wire between AUX1
and COM
Wire dry contact switch between AUX3
and COM (now called SW3)
Wire dry contact switch between AUX4
and COM (now called SW4)
Toggle SW4 until you see INFINITE
RESTARTS on screen
Toggle SW3 to select between YES or
NO
Wait several seconds until “Programmed Successfully” is shown on the display, and then
return switches to the OFF position. Turn power to converter OFF, re-install jumper wire
between AUX1 and COM, then reapply power to converter.
