Table 14 – Input Power Terminal Specifications - PT
Input Power Terminals: Allowed Wire Range & Minimum Torque
Model
PT007, PT010, PT020,
PT407, PT410, PT415,
PT420, PT430, PT440,
PT450
PT030, PT040, PT460,
PT475
PT050, PT060, PT075,
PT4100
Wire Size
Torque
Wire Size
Torque
Wire Size
Torque
2/0 – 6 AWG
120 in-lb
350 kcmil-
6 AWG
275 in-lb
2x500 kcmil-
2x4 AWG
375 in-lb
8 AWG
40 in-lb
10 – 14 AWG
35 in-lb
Table 15 – Input Power Terminal Specifications - PTE
Input Power Terminals: Allowed Wire Range & Minimum Torque
Model
PTE007, PTE007QT, PTE010, PTE010QT, PTE207,
PTE210, PTE215, PTE220, PTE407, PTE407QT, PTE410,
PTE410QT, PTE415QT, PTE420QT
PTE015, PTE020
Wire Size
Torque
Wire Size
Torque
2 – 20 AWG
17.5 in-lb
2/0 – 6 AWG
8 AWG
10 – 14 AWG
120 in-lb
40 in-lb
35 in-lb
Table 16 – Output Power Terminal Specifications
Output Power Terminals: Allowed Wire Range & Minimum Torque
Model
PT007, PT010, PT020, PT030, PT040,
PT407, PT410, PT415, PT420, PT430,
PT440, PT450, PT460, PT475
PT050, PT060, PT075, PT4100
Wire Size
Torque
Wire Size
Torque
2/0 – 6 AWG
120 in-lb
350 kcmil – 6 AWG
275 in-lb
8 AWG
40 in-lb
10 – 14 AWG
35 in-lb
Table 17 – Output Power Terminal Specifications - PTE
Output Power Terminals: Allowed Wire Range & Minimum
Torque
Model
PTE007, PTE007QT, PTE010, PTE010QT, PTE015, PTE020,
PTE207, PTE210, PTE215, PTE220, PTE407, PTE407QT
PTE410, PTE415QT, PTE420QT
Wire Size
Torque
4 – 18 AWG
16 in-lbs
