Figure 21 – Panel Shop Options
WARNING! When the converter is turned OFF using a switch on the AUX terminals,
dangerous voltage may still be present on the input lines and elsewhere inside the
enclosure. Never open the enclosure or perform maintenance on the unit or
connected loads when the incoming power to the phase converter is ON, regardless
of the switch setting.
Table 21 – Control Terminal Ratings and Descriptions
CAUTION! Electrostatic discharge (ESD) can damage electronic components.
Discharge ESD prior to touching the board or making connections. To discharge ESD,
touch your hand to unpainted metal on the enclosure.
