Figure 33 – PT Small Frame Fuse Location
Figure 34 – PT Medium Frame Fuse
Location
Figure 35 – PT Large Frame Fuse Locations
Some PTE models may require the heat sink baffle to be removed before accessing fuses.
To do this, remove the screws fastening the baffle to the side of the heatsink.
The heat sink baffle is necessary for proper cooling and must be replaced before
resuming operation. If not properly replaced, warranty may be voided.
Figure 36 – PTE Frame 2 Fuse Location
(Heat Sink Baffle Must Be Removed)
Small Frame Models:
PT407, PT410, PT415,
PT420
Medium Frame Models:
PT007, PT010, PT020,
PT430
Large Frame Models:
PT030, PT040, PT050,
PT060, PT075, PT440,
PT450, PT460, PT475,
PT4100
