XF Camera System | IQ Backs for Mamiya RZ PRO IID
36
IQ back on a Mamiya RZ PRO IID
The IQ backs with XF mount or 645DF+ mount are compatible
with the Mamiya RZ Pro IID camera, however this will require
an adaptor plate. (Phase One Part # 70994)
It is possible to use a Hasselblad V mount IQ back on the
Mamiya RZ67 PRO IID by getting the back mount plate modified
with the following Mamiya service part number: Y22995-RZ.
IQ back on older Mamiya RZ PRO II
Only the Hasselblad V version of an IQ back can be used on
the older version Mamiya RZ PRO II with a Mamiya RZ Pro II
adaptor. (Phase One Part# 70964)
Mounting IQ Back on the Mamiya RZ PRO II
Viewfinder Mask
Please check the relevant Mamiya RZ67 manual regarding how
to dismount the viewfinder and remove the focus screen.
1. Remove the protection tape from the mask.
2. Dismount the prism/waist-level finder and remove the
focus screen.
3. Place the viewfinder mask in the bracket that holds the
focusing screen.
4. Re-mount the viewfinder focus screen followed by the
Viewfinder.
Mamiya RZ Pro II mode selector
The mode selector on the trigger button should be turned to the
white dot when used with the IQ back. The selector should be set
to the orange dot to avoid draining the small battery of the RZ
camera when the IQ back is attached to the body and not in use.
IQ Camera Mode
Select the special Mamiya RZPRO IID camera mode in the IQ
back Menu>Camera mode, this will ensure that the IQ knows it
is mounted to a Mamiya RZ PRO II.
