Phenix Technologies BK130 - Page 13

BK-130
4-3
INITIAL SET-UP--ELECTRICAL
Figure 4-1
TYPICAL TEST CONNECTIONS FOR CATEGORIES 'A' & 'B' AERIAL DEVICES
BONDING
JUMPER
BONDING
JUMPER
BONDING
JUMPER
EARTH or FACILITY
GROUND
HV
TRANSFORMER
CONTROLS



 
















