Phenix Technologies BK130 User Manual

BK-130
16-2
BK-130 PARTS LIST
Bubble No
Part Number
Description
Quantity
CONTROL SECTION (Cont’d)
GRN/YEL TESTLEAD
30080018
20 FT LARGE BLACK TEST LEAD
20FT
INPUT- CBL (120V)
30110008
30 FT 10/3 POWER INPUT CABLE
1
INPUT- CBL (220V)
30110028
30 FT 14/3POWER INPUT CABLE
1
TMR1
1480120
PANEL MOUNT DIG TIMER, OMEGA #PTC-13
1
P2
1151179
OUTPUT TO TRANSFORMER RECEPTACLE
1
P2
1151185
FEMALE CONTACT PINS
2
INTER-MTR CBL (TX1)
30160001
20FT SIG / METERING INTERCONNECT CABLE
1
HANDTRUCK
HANDTRUCK
48660004
HANDTRUCK ASSY
1
LATCHES
2371043
CASE TO CART LATCHES
2
HIGH VOLTAGE SECTION
BP-GROUND
1351100
BINDING POST 459 BLACK
1
BP-GUARD
1351104
BINDING POST 459 WHITE
1
BP-RETURN
1351102
BINDING POST 459 RED
1
BP-SHORT BAR
1351110
SHORTING BAR
1
D3001-4
1780066
13V TRANZORB
4
MOV3001-3 (120 V)
31107000
METAL OXIDE VARISTOR ASSY
1
MOV 3001-3 (220 V)
1606110
V275LA40 MOVISTOR
3
R3001, 3002
1748410
200MEGS,1%,6W ROX4ST {SSX103}
4
R3003, 3004
1724400
0.5W,200K,1%
2
R3005
1740199
3W, 110, 1%
1
R3007
1722570
0.25W, 30K, 1%
1
R3008
1722087
0.25W, 3.0K, 1%
1
R3009
1720600
0.5W, 300 , 1%
1
R3010
1740185
10W, 30, 1%
1
SG3001-4
1605110
CGL90L, SPARKGAP 90V
4
T3001
38342040
GO2040
1
TX1
1151158
TX1 CHASSIS CONNECTOR
1
TX1
1151170
20 GUAGE PINS
9
SPINNING
2401340
AL. SPNG, 3 “X12” FS12603
1
LUNDEY
2410125
¼ - 20 LUNDEY
9
CON CAPS
1151196
CONNECTOR CAPS – PROTECTIVE
2
P3001
1151178
POWER CHASSIS CONNECTOR
1
P3001
1151183
MALE PINS
2
PCB
1112232
PCB 1223
1
S.S. BALL
2403120
2” POLISHED STAINLESS STEEL BALL
1
OPTIONAL ACCESSORIES
STROBE LIGHT &
POLE
48660005
TELESCOPING STROBE LIGHT ASSY.
1
ALUMINUM COVER
9607031
ALUMINUM COVER
1
Contact the Phenix Technologies Service Department Customer Service Coordinator for
pricing of accessories.
