Phenix Technologies BK130 User Manual

BK-130
16-1
`SECTION 16: BK -130 PARTS LIST
Bubble No
Part Number
Description
Quantity
CONTROL SECTION
CB1 (120 V)
1601330
AM1-A3-A-30-2,250V 1 Pole Breaker
1
CB1 (220 V)
1601317
AM2-A3-A-15-2, 250V 2 Pole Breaker
1
CB2 (120 V)
1601332
30 AMP 2 POLE BREAKER
1
CB2 (220 V)
1601317
AM2-A3-A-15-2, 250 V 2 Pole Breaker
1
F1 (120 V)
1603622
2 AMP AGC,250V
1
F1,2 (220 V)
1603601
1 AMP AGC, 250 V
2
F1,F2
1603920
#3456613A FUSEHOLDER 3AG
1 or 2
HANDLES
2101710
HANDLE,10501-005,3RU
2
K3 (120 V)
1705460
FUR.#45CG10AFA SP 25A
1
K3 (220 V)
1705462
FUR # 42F35AF 25A / 3P 120 V
1
LEAD
1353048
PLIER TYPE BATTERY CLIP RED, BU46C-2
1
LEAD
1353050
PLIER TYPE BATTERY CLIP BLACK, BU46C-O-
1
LP1,SW10,SW11
1422153
31-903.7 LENS CLEAR
3
LP1
1423300
31-040-005 SOCKET
1
M1,M2
1506400
KNS 3 ½ DIGIT LCD, DMO-66T
2
CKT BD ASSY.
31125704
CONTROL/METERING BD
1
MOV1 (120 V)
1606100
V130LA10 MOVISTOR
1
MOV1 (220 V )
1606110
V275LA40 MOVISTOR
1
P1
1151178
MAIN INPUT RECEPTACLE
1
P1
1151183
MALE CONTACT PINS
3
POWER CBL(120V)
30110007
PWR CBL, 10/2 20FT, INTERCONNECT
1
POWER CBL(220V)
30110029
PWR CBL, 14/2 20FT, INTERCONNECT
1
R15
1761098
10k,2W LINEAR {01F2644}
1
R15-DIAL
1355910
46-15-010 DIAL 30-0-011
1
R15 KNOB
1355101
26-15-61-3 KNOB
1
R15 -CAP
1355102
31-15-10-1 PEAKED CAP
1
R15-KNOB
1355905
47-15-023 STATOR BLACK
1
SW2/ LP2
1422150
31-903.2 LENS, EAO RED
1
SW2,3,4
1860120
31-121.025 EAO, MOM 1 POLE
3
LP1, 2,3,4,SW10
1420150
31-963.4 LAMP 60V
5
SW4/ LP4
1422148
31-903.6 LENS, BLUE
1
SW7
1866005
2HBA190-1 ROLLER 20A
1
SW3/ LP3
1422151
31-903.5 LENS GREEN
1
SW5, SW9
1355310
KNB PKAP-50B-1/4
2
SW5,SW9
1863042
PA-2010 ROTARY 4P 2-6POS-S.
2
SW10
1860265
31-262.025 EAO, LATCH 2 POLE
1
SW11
1860260
31-261.025 EAO, LATCH 1 POLE
1
SW8
1860900
LATCHING MUSHROOM PB W / KEY
1
SW8
1862905
SIEMENS#3SB1400-OC,NC
1
SX1
1151152
EXT. INTLK. RECEPTACLE- CHASSIS
1
SX1
1151174
FEMALE PINS
2
SX1
1151162
EXT. INTLK. PLUG (CABLE)
1
SX1
1151186
EXT. INTLK. CABLE CLAMP
1
SX1
1151176
SOLDER TYPE MALE PINS
2
T1 (120 V)
1890230
1510 VARIABLE STACO
1
T1 (220 V )
1890234
1520 VARIABLE STACO
1
T2 (220 V)
1896017
SEIMENS # MT 0050A
1
TX1
1151158
AMP 16 PIN CHASSIS CONNECTOR
1
TX1
1151170
MALE PINS
10
RED TEST LEAD
30080010
20FT LARGE RED TEST LEAD
20FT
