Philips 191E2SB/00 - Converter Board

45
Meridian 2
Step 3: Remove the bezel
1. Remove the Scaler Board assy.
2. Remove the Inverter Board assy.
191E2
3. Remove the Converter Board assy.
191EL2
4. Disconnect the key cable.
Step 4: Remove the panel
1. Press to release left and right latches of LVDS cable
and disconnect the LVDS cable.
2. Disconnect the lamp connectors.
191E2
191EL2
This Connector is
optional for some
models.
