3.2.2 DVI -D Cable
The input signals are applied to the display through DVI-D cable.
Length : 1.8 M +/- 50 mm
Connector type : DVI-D male with DDC-2B pin assignments
White connector thumb-operated jackscrews
Pin Assignment:
Pin No. Description Pin No. Description
1 T.M.D.S. data2- 13 No Connect
2 T.M.D.S. data2+ 14 +5V Power
3 T.M.D.S. data2 shield 15 Ground (for +5V)
4 No Connect 16 Hot plug detect
5 No Connect 17 T.M.D.S. data0-
6 DDC clock 18 T.M.D.S. data0+
7 DDC data 19 T.M.D.S. data0 shield
8 No Connect 20 No Connect
9 T.M.D.S. data1- 21 No Connect
10 T.M.D.S. data1+ 22 T.M.D.S clock shield
11 T.M.D.S. data1 shield 23 T.M.D.S. clock+
12 No Connect 24 T.M.D.S. clock-
3.3 Timing requirement
Factory Preset mode definition:
a. Perfect FOS while presenting all required timings.
b. Required timings need to be specified in User's Manual
User mode
a. Can be showed (not over scalar or Panel spec.)
b. It needs to reserve the 22 timings space in memory size.
3.3.1 Mode storing capacity
a. Factory preset modes : 18
b. User modes : 33
Note:
11. Screen displays perfect picture at factory-preset modes.
12. Screen displays visible picture with OSD warning when input modes are the 22reset modes
3.3.2 Factory preset modes
Factory modes and preset modes are defined in the enclosed timing table file
˄ˌ˄˘˅ˁ˿
Video timing mode (internal firmware support),
60Hz: 480p/720p/1080i/1080p
50Hz: 576p/720p/1080i/1080p
