12. ISP Instruction
When do the parts, need the tools as follow:
A. An i486 (or above) personal computer or compatible.
B. Microsoft operation system Windows 95/98/2000/XP.
C. “PORT95NT.exe” and “ISP_Tool V4.3.4.exe” programs
D. ISP Board (715GT039-A) x1, Printer cablex1, VGA cable x1
E. software
12.1 Double Click to install the “PORT95NT.exe”, and then restart the computer.
12.2. Connect the ISP board as follows:
12.3 The process of ISP writing as follows (take the 221E1 for example):
1. Double-click to running the program as follows:
Connect to
the PC LPT
Connect this port to the
Philips model VGA port
To Next Page
