2.1.4 Connecting NetCam2 to a PC using crossover cable
FIgure 2-2
Connecting NetCam2 to a PC using a crossover (cross link) Network cable.
2.1.5 Connecting NetCam2 to a PC via a HUB
FIgure 2-3
Connecting NetCam2 to a PC via a HUB, using ‘Direct’ cables.
12
NetCam2 Section 2
Crossover cable (red)
Select 'IP Address'
HUB
2
