Philips 21PT9457 - Keyboard & Control Panel [D]; BTSC Panel [K]

Spare Parts List
EN 54 SK4.0L CA10.
R326 9965 000 39977 CFR 100kΩ
R327 9965 100 04854 1.5kΩ 5% 1W
R401 9965 000 40686 CFR 15kΩ 1/16W
R402 9965 000 40686 CFR 15kΩ 1/16W
R405 9965 000 40304 CFR 1KΩ 1/16W
R406 9965 000 40304 CFR 1KΩ 1/16W
R407 9965 000 39976 CFR 10kΩ 1/16W
R408 9965 000 40700 CFR 4.7kΩ 1/16W
R409 9965 000 40695 CFR 3.3kΩ 1/16W
R410 9965 100 04837 130kΩ 5% 1/16-1/6W
R411 9965 000 39976 CFR 10kΩ 1/16W
R501 9965 000 40690 CFR 22Ω 1/16W
R502 9965 100 04839 2.2kΩ 5% 1/6W
R503 9965 000 40491 CFR 270Ω 1W
R504 9965 000 40690 CFR 22Ω 1/16W
R505 9965 100 04858 270Ω 5% 1W
R506 9965 000 40517 MOFR 15kΩ
R507 9965 100 04856 220Ω 5% 1W
R508 9965 100 04853 1kΩ 5% 1W
R510 9965 000 39998 CFR 22Ω 1/4W
R511 9965 000 40000 CFR 2.2kΩ
R512 9965 000 39998 CFR 22Ω 1/4W
R513 9965 000 40491 CFR 270Ω 1W
R514 9965 100 04858 270Ω 5% 1W
R515 9965 000 40517 MOFR 15kΩ
R516 9965 100 04856 220Ω 5% 1W
R517 9965 100 04853 1kΩ 5% 1W
R519 9965 000 40503 CFR 220kΩ 1W
R520 9965 100 04839 2.2kΩ 5% 1/6W
R521 9965 000 39998 CFR 22Ω 1/4W
R522 9965 000 39998 CFR 22Ω 1/4W
R523 9965 000 40491 CFR 270Ω 1W
R524 9965 100 04858 270Ω 5% 1W
R525 9965 000 40517 MOFR 15kΩ
R526 9965 100 04856 220Ω 5% 1W
R527 9965 100 04853 1k
Ω 5% 1W
R601 9965 000 40150 High Volt. 2.2MΩ 1/2W
R602 9965 100 04857 220kΩ 5% 1W
R603 9965 000 40524 NTC 5/5A
R604 9965 000 40698 CFR 39kΩ 1/16W
R605 9965 000 40691 CFR 220Ω 1/16W
R606 9965 000 40706 CFR 6.8kΩ 1/16W
R607 9965 000 39998 CFR 22Ω 1/4W
R608 9965 100 04839 2.2kΩ 5% 1/6W
R609 9965 000 40154 High Volt. 8.2MΩ 1W
R611 9965 100 04849 680Ω 5% 1/16-1/6W
R612 9965 100 04839 2.2kΩ 5% 1/6W
R613 9965 000 40304 CFR 1KΩ 1/16W
R614 9965 100 04845 4.3kΩ 5% 1/16-1/6W
R615 9965 000 40490 CFR 220kΩ 1W
R616 9965 100 04862 0.22Ω 5% 1W
R617 9965 100 04863 0.33Ω 5% 1W
R618 9965 100 04863 0.33Ω 5% 1W
R619 9965 100 04858 270Ω 5% 1W
R621 9965 100 04855 22Ω 5% 1W
R622 9965 100 04851 820Ω 5% 1/16-1/6W
R623 9965 000 40101 CFR 3.3kΩ
R624 9965 000 39976 CFR 10kΩ 1/16W
R625 9965 000 39976 CFR 10kΩ 1/16W
R626 9965 000 39976 CFR 10kΩ 1/16W
R630 9965 000 39999 CFR 220Ω
R632 9965 000 39976 CFR 10kΩ 1/16W
R633 9965 000 40304 CFR 1KΩ 1/16W
R637 9965 000 40517 MOFR 15kΩ
R638 9965 000 39984 CFR 75Ω 1/16W
R639 9965 000 39976 CFR 10kΩ 1/16W
R640 9965 100 04937 Bead 3.5 X 1 X 5mm
R640 9965 100 06020 Bead 3.5 X 1 X 5mm
R801 9965 000 40705 CFR 68Ω 1/16W
R802 9965 100 04838 180Ω 5% 1/16-1/6W
R804 9965 100 05140 2.4kΩ 5% 1/16-1/6W
R805 9965 100 05140 2.4kΩ 5% 1/16-1/6W
R806 9965 000 39975 CFR 100Ω
1/16W
R807 9965 000 39975 CFR 100Ω 1/16W
R817 9965 100 05140 2.4kΩ 5% 1/16-1/6W
R818 9965 100 05140 2.4kΩ 5% 1/16-1/6W
R835 9965 000 39976 CFR 10kΩ 1/16W
R836 9965 000 39976 CFR 10kΩ 1/16W
R841 9965 000 40700 CFR 4.7kΩ 1/16W
R842 9965 000 40700 CFR 4.7kΩ 1/16W
R843 9965 000 40252 Peaking coil 10μH 10%
R844 9965 000 39975 CFR 100Ω 1/16W
R847 9965 000 39975 CFR 100Ω 1/16W
R852 9965 000 40685 CFR 1.5kΩ 1/16W
R854 9965 000 40685 CFR 1.5kΩ 1/16W
RST601 9965 100 04856 220Ω 5% 1W
RT602 9965 100 04865 Ther Resistor 9Ω for 29"
VR601 9965 000 40155 Semi-fixed R 1KB (H)
b
J807 9965 100 04921 Peaking Coil 56μH 10%
J808 9965 100 04921 Peaking Coil 56μH 10%
J835 9965 100 04921 Peaking Coil 56μH 10%
J836 9965 100 04921 Peaking Coil 56μH 10%
J837 9965 100 04921 Peaking Coil 56μH 10%
J838 9965 100 04921 Peaking Coil 56μH 10%
J849 9965 000 40700 CFR 4.7kΩ 1/16W
l601 9965 000 41227 Bead 3.5 x 1 x 9mm
L101 9965 000 40602 Peaking coil 1μH 10%
L102 9965 000 40253 Peaking coil 100μH 10%
L103 9965 100 04921 Peaking Coil 56μH 10%
L201 9965 000 40252 Peaking coil 10μH 10%
L202 9965 000 40252 Peaking coil 10μH 10%
L203 9965 000 40252 Peaking coil 10μH 10%
L204 9965 000 40252 Peaking coil 10μH 10%
L205 9965 000 40252 Peaking coil 10μH 10%
L206 9965 100 04920 Peaking Coil 6.8μH
L301 9965 100 04922 Choke Coil 105μH
L302 9965 100 07718 Linear Coil 36μH
L303 9965 100 07717 Choke Coil 2.8MHz 10%
L304 9965 100 04924 Choke Coil 790μH
L401 9965 000 40252 Peaking coil 10μH 10%
L501 9965 000 40252 Peaking coil 10μH 10%
L605 9965 000 40255 Choke coil 100μH 10%
L801 9965 100 04847 560Ω 5% 1/16-1/6W
L802 9965 100 04847 560Ω 5% 1/16-1/6W
L805 9965 100 04847 560Ω 5% 1/16-1/6W
L806 9965 100 04847 560Ω 5% 1/16-1/6W
T301 9965 100 04931 21" Transformer B+115V
T302 9965 100 05412 Transformer BCT-19G
T302 9965 100 07484 Horizontal Drive Transf.
T601 9965 100 05324 Line Filter 30mH x 2
T602 9965 100 05324 Line Filter 30mH x 2
T604 9965 100 04932 Switching Transf. Ec40
d
D101 9965 000 40221 Zener 5V1 1/2W 5%
D201 9965 000 40221 Zener 5V1 1/2W 5%
D202 9965 000 40224 Zener 8V2 1/2W 5%
D203 9965 000 40224 Zener 8V2 1/2W 5%
D204 9965 000 40224 Zener 8V2 1/2W 5%
D205 9965 000 40218 1N4148 150mA/100V
D206 9965 000 41175 6V2 5% 1/2W
D207 9965 000 40221 Zener 5V1 1/2W 5%
D301A 9965 000 40224 Zener 8V2 1/2W 5%
D302 9965 000 40219 BA158 600V/1A
D303 9965 000 40219 BA158 600V/1A
D304 9965 000 40219 BA158 600V/1A
D305 9965 000 40218 1N4148 150mA/100V
D306 9965 000 40224 Zener 8V2 1/2W 5%
D307 9965 000 40218 1N4148 150mA/100V
D308 9965 000 40219 BA158 600V/1A
D309 9965 100 04909 Zener Diode 18V 1/2W
D310 9965 000 40219 BA158 600V/1A
D311 9965 100 04906 3A/800V(DO-27)
D312 9965 100 04904 BY228
D401 9965 000 40218 1N4148 150mA/100V
D402 9965 000 40218 1N4148 150mA/100V
D501 9965 000 40218 1N4148 150mA/100V
D502 9965 000 40219 BA158 600V/1A
D503 9965 000 40218 1N4148 150mA/100V
D504 9965 000 40219 BA158 600V/1A
D505 9965 000 40218 1N4148 150mA/100V
D506 9965 000 40219 BA158 600V/1A
D603 9965 000 40219 BA158 600V/1A
D604 9965 100 04909 Zener Diode 18V 1/2W
D605 9965 100 04911 TA20-08 2A/800V
D606 9965 100 04911 TA20-08 2A/800V
D607 9965 100 04911 TA20-08 2A/800V
D608 9965 100 04911 TA20-08 2A/800V
D609 9965 100 04907 3V6 1/2W +/-5%
D610 9965 100 07483 High Speed Rect. RU4
D611 9965 100 04906 3A/800V(DO-27)
D612 9965 000 40219 BA158 600V/1A
D613 9965 100 04905 TRU3YX 200V/2A
D615 9965 000 40219 BA158 600V/1A
D616 9965 000 40220 Zener 3V9 1/2W 5%
D617 9965 000 40218 1N4148 150mA/100V
D801 9965 000 40224 Zener 8V2 1/2W 5%
D802 9965 000 40224 Zener 8V2 1/2W 5%
D803 9965 000 40224 Zener 8V2 1/2W 5%
D804 9965 000 40224 Zener 8V2 1/2W 5%
D805 9965 000 40224 Zener 8V2 1/2W 5%
ce
IC101 9965 000 40249 KA33V
IC201 9965 100 07701 uP
IC202 9965 000 40597 8k-BIT IIC EEPROM
IC301 9965 100 04918 TDA4865AJ DBS7P
IC401 9965 000 40596 TDA9859
IC402 9965 100 04917 TFA9842AJ PHILIPS
IC601 9965 100 04916 STR-W6554A SANKEN
IC602 9965 100 04915 TLP421 TOSHIBA
IC604 9965 000 40247 L7808CV
Q101 9965 000 40584 2SC3779D
Q201 9965 000 40232 2SC1815Y/2PC1815
Q204 9965 000 40232 2SC1815Y/2PC1815
Q302 9965 100 04914 3DD5032/D5032
Q303 9965 000 41191 Trans. FQPF630
Q401 9965 000 40232 2SC1815Y/2PC1815
Q402 9965 000 40231 2SA1015Y\2PA1015
Q450 9965 000 40234 2SC2482/3DG2482Y
Q501 9965 000 40238 BF422 NPN (250V)
Q502 9965 000 40239 BF423 PNP (-250V)
Q503 9965 000 40238 BF422 NPN (250V)
Q504 9965 000 40238 BF422 NPN (250V)
Q505 9965 000 40239 BF423 PNP (-250V)
Q506 9965 000 40238 BF422 NPN (250V)
Q507 9965 000 40238 BF422 NPN (250V)
Q508 9965 000 40239 BF423 PNP (-250V)
Q509 9965 000 40238 BF422 NPN (250V)
Q601 9965 100 06016 KA431Z Fairchild
Q602 9965 100 04913 Transistor 2SC2120Y
Q603 9965 000 40232 2SC1815Y/2PC1815
Q604 9965 000 40232 2SC1815Y/2PC1815
Q606 9965 100 04912 2SA1013
Q608 9965 000 40231 2SA1015Y\2PA1015
Q803 9965 000 40232 2SC1815Y/2PC1815
Q804 9965 000 40232 2SC1815Y/2PC1815
GST601 9965 000 40274 Surge Abs. 300V 30%
J241 9965 000 40252 Peaking coil 10μH 10%
J249 9965 000 40252 Peaking coil 10μH 10%
J625 9965 000 40218 1N4148 150mA/100V
J629 9965 000 39975 CFR 100Ω 1/16W
J632A 9965 000 40700 CFR 4.7kΩ 1/16W
Keyboard & Control Panel [E]
Various
SW002 9965 100 04934 Tact Switch
SW004 9965 100 04934 Tact Switch
g
CR1 9965 100 04879 10μF 20% 10V
f
RD2 9965 000 40693 CFR 2.7kΩ 1/16W
RD3 9965 000 39975 CFR 100Ω 1/16W
RD4 9965 000 40688 CFR 18kΩ 1/16W
RD5 9965 000 39976 CFR 10kΩ 1/16W
M001 9965 000 40270 IR receiver mod. 36kHz
BTSC Board [K]
Various
X801 9965 100 07714 Cer. Res. 503kHz
g
C801 9965 100 05388 1µF 20% 50V
C802 9965 100 07708 0.47µF 10% 63-100V
C803 9965 000 41112 4.7μF 20% 16V
C804 9965 100 07706 0.22μF 50V
C805 9965 000 40171 10μF 20% 16V
C806 9965 000 41112 4.7μF 20% 16V
C807 9965 000 41112 4.7μF 20% 16V
C808 9965 000 40561 Mylar 0.015μF 100V
C809 9965 000 40171 10μF 20% 16V
C810 9965 000 40171 10μF 20% 16V
C811 9965 000 40178 1μF 20% 50V
C812 9965 000 40178 1μF 20% 50V
C813 9965 100 07707 0.047µF 50V
C814 9965 000 40171 10μF 20% 16V
C815 9965 000 40157 0.1μF 50V
C816 9965 000 41112 4.7μF 20% 16V
C817 9965 000 40157 0.1μF 50V
C818 9965 000 40172 100μF 20% 16V
C819 9965 000 40172 100μF 20% 16V
C821 9965 100 05388 1µF 20% 50V
C822 9965 100 05388 1µF 20% 50V
C823 9965 000 40180 2.2μF20% 50V
C824 9965 000 40180 2.2μF20% 50V
C825 9965 000 41097 100pF 50V
C826 9965 000 41097 100pF 50V
C827 9965 000 40171 10μF 20% 16V
C828 9965 000 40157 0.1μF 50V
C829 9965 100 05388 1µF 20% 50V
