Spare Parts List
EN 53SK4.0L CA 10.
10. Spare Parts List
Set Level
Various
CRT 9965 100 07893 21HUAFEI C.P.T
A51ERU191X03/
Speaker A 9965 100 04936 Loudsp. 8Ω 10W
Speaker B 9965 100 04936 Loudsp. 8Ω 10W
SW601 9965 100 04935 MPS.SDDF-3-03
Main Board [B]
Various
A101 9965 100 07704 Tuner
F601 9965 100 05334 Fuse T5A 250V
S501 9965 000 40278 CRT Socket
SAW101 9965 100 07702 SAW SW05 45.75MHz
X201 9965 100 06018 Crystal 12.000000MHz
Z202 9965 100 07703 Ceramic Trap 4.5MHz
ZD501 9965 000 40224 Zener 8V2 1/2W 5%
g
C101 9965 000 41097 100pF 50V
C102 9965 000 41097 100pF 50V
C103 9965 000 40171 10μF 20% 16V
C104 9965 000 40172 100μF 20% 16V
C105 9965 000 40156 0.01μF 50V
C106 9965 100 04885 0.47uF 20% 50V
C107 9965 000 40156 0.01μF 50V
C110 9965 000 40156 0.01μF 50V
C201 9965 000 41097 100pF 50V
C202 9965 000 41097 100pF 50V
C203 9965 000 40156 0.01μF 50V
C206 9965 000 40171 10μF 20% 16V
C207 9965 100 04892 0.22μF 5% 63-100V
C208 9965 100 04870 0.0047μF +80-20% 50V
C209 9965 100 04867 0.0022μF +80-20% 50V
C210 9965 100 04892 0.22μF 5% 63-100V
C211 9965 000 40178 1μF 20% 50V
C212 9965 000 40156 0.01μF 50V
C213 9965 100 06012 Met. Polyester Filmcap.
C214 9965 100 04866 0.001uF 5% 50V
C215 9965 100 04866 0.001uF 5% 50V
C216 9965 100 04866 0.001uF 5% 50V
C217 9965 100 04891 0.1μF 5% 63-100V
C218 9965 000 40180 2.2μF20% 50V
C219 9965 000 40156 0.01μF 50V
C220 9965 000 40171 10μF 20% 16V
C221 9965 100 07709 180pF 50V
C222 9965 000 40171 10μF 20% 16V
C223 9965 000 40208 Mylar 0.0015μF 100V
C224 9965 100 04873 390pF 10% 500V
C226 9965 000 41097 100pF 50V
C227 9965 000 40176 470μF 20% 16V
C229 9965 000 40529 33pF 50V
C230 9965 000 40529 33pF 50V
C231 9965 000 40172 100μF 20% 16V
C232 9965 000 40156 0.01μF 50V
C233 9965 000 40156 0.01μF 50V
C234 9965 000 40171 10μF 20% 16V
C235 9965 000 40156 0.01μF 50V
C236 9965 000 40171 10μF 20% 16V
C237 9965 100 04871 560pF 5% 50V
C238 9965 000 40179 10μF 20% 50V-63V
C239 9965 100 04868 0.022μF +80-20% 50V
C240 9965 100 04868 0.022μF +80-20% 50V
C241 9965 100 04868 0.022μF +80-20% 50V
C243 9965 000 40172 100μF 20% 16V
C244 9965 000 40156 0.01μF 50V
C245 9965 000 40171 10μF 20% 16V
C246 9965 100 05386 0.01μF 5% 100V
C247 9965 000 40158 220pF 50V
C248 9965 000 40175 47μF 20% 16V
C253 9965 000 40180 2.2μF20% 50V
C300 9965 100 04874 470pF 10% 500V
C301 9965 100 04874 470pF 10% 500V
C302 9965 100 04874 470pF 10% 500V
C303 9965 100 06011 EC.1000uF 25V +/-20%
C304 9965 100 06011 EC.1000uF 25V +/-20%
C305 9965 100 07710 220µF
C306 9965 100 04891 0.1μF 5% 63-100V
C307 9965 100 04891 0.1μF 5% 63-100V
C308 9965 100 04891 0.1μF 5% 63-100V
C309 9965 100 05317 47μF 20% 250V
C310 9965 000 40163 220pF 500V
C311 9965 100 04887 4.7μF 20% 250V
C312 9965 100 04890 0.027UF 5% 630V
C314 9965 100 04894 0.0027μF 5% 2kV
C315 9965 100 05222 0.0068μF 5% 2kV
C316 9965 000 40558 0.0082μF 5% 2kV
C317 9965 100 04893 0.78μF 5% 400V
C318 9965 100 04888 0.27μF 5% 400V
C319 9965 000 41107 CerCap 680pF 2kV
C321 9965 000 40164 CerCap 0.0022μF 500V
C323 9965 000 40180 2.2μF20% 50V
C325 9965 000 41097 100pF 50V
C325 9965 100 04889 PFC.0.36uF 400V +/-5%
C326 9965 000 41097 100pF 50V
C327 9965 000 41099 0.001μF 500V
C405 9965 000 40172 100μF 20% 16V
C406 9965 000 40175 47μF 20% 16V
C407 9965 000 40156 0.01μF 50V
C408 9965 100 05389 0.068μF 10% 100V
C409 9965 100 04891 0.1μF 5% 63-100V
C410 9965 000 40563 Mylar 0.0056UF 100V
C413 9965 000 40179 10μF 20% 50V-63V
C414 9965 000 40179 10μF 20% 50V-63V
C415 9965 000 41097 100pF 50V
C416 9965 000 41097 100pF 50V
C417 9965 000 40179 10μF 20% 50V-63V
C419 9965 000 40563 Mylar 0.0056UF 100V
C420 9965 100 04891 0.1μF 5% 63-100V
C421 9965 100 05389 0.068μF 10% 100V
C422 9965 000 40561 Mylar 0.015μ
F 100V
C423 9965 000 40561 Mylar 0.015μF 100V
C424 9965 000 40561 Mylar 0.015μF 100V
C425 9965 000 40561 Mylar 0.015μF 100V
C426 9965 000 40179 10μF 20% 50V-63V
C428 9965 100 04885 0.47uF 20% 50V
C429 9965 000 40545 220μF 20% 25V
C430 9965 000 40157 0.1μF 50V
C432 9965 000 40172 100μF 20% 16V
C433 9965 100 04883 1000μF 20% 25V
C434 9965 100 04883 1000μF 20% 25V
C436 9965 000 40172 100μF 20% 16V
C477 9965 100 04902 4.7μF 20% 480mA 50V
C501 9965 000 40159 330pF 50V
C502 9965 000 40159 330pF 50V
C503 9965 000 40159 330pF 50V
C504 9965 000 41105 CerCap 0.001mF 2kV
C504 9965 100 04876 0.001μF 10% 2kV
C508 9965 100 04866 0.001uF 5% 50V
C509 9965 100 05315 47μF 250V
C601 9965 000 40567 0.1μF A C250V-500V
C602 9965 000 40568 Line Filter 30MHz X 2
C603 9965 000 40565 0.001μF 250V-400V
C604 9965 000 40565 0.001μF 250V-400V
C605 9965 000 41100 0.0047μF 500V
C608 9965 000 41100 0.0047μF 500V
C609 9965 000 40564 220μF
C610 9965 000 40179 10μF 20% 50V-63V
C611 9965 100 04891 0.1μF 5% 63-100V
C612 9965 000 40531 470pF 50V
C613 9965 000 40156 0.01μF 50V
C614 9965 000 41163 0.0022μF 20% 250V
C615 9965 000 40161 CerCap 390pF 50V
C616 9965 000 40551 47μF 20% 160V
C617 9965 100 04901 100μF 20% 160V
C618 9965 100 04878 220pF 10% 2kV
C619 9965 100 04875 470pF 10% 1kV
C620 9965 100 04875 470pF 10% 1kV
C621 9965 100 06011 EC.1000uF 25V +/-20%
C622 9965 100 04886 470uF 20% 50V
C625 9965 000 40541 2200μF
C626 9965 000 40156 0.01μF 50V
C627 9965 100 04883 1000μF 20% 25V
C628 9965 100 04881 1000μF 20% 16V
C628A 9965 100 04883 1000μF 20% 25V
C631 9965 000 40176 470μF 20% 16V
C633 9965 100 07724 0.001µF 2kV
C634 9965 000 40173 1000μF
C637 9965 100 04875 470pF 10% 1kV
C801 9965 000 41097 100pF 50V
C802 9965 000 40171 10μF 20% 16V
C803 9965 000 41097 100pF 50V
C804 9965 000 40179 10μF 20% 50V-63V
C805 9965 000 41097 100pF 50V
C806 9965 000 41097 100pF 50V
C807 9965 000 40179 10μF 20% 50V-63V
C808 9965 000 40179 10μF 20% 50V-63V
C809 9965 000 40179 10μF 20% 50V-63V
C810 9965 000 40179 10μF 20% 50V-63V
C811 9965 000 40179 10μF 20% 50V-63V
C812 9965 000 41097 100pF 50V
C813 9965 000 41097 100pF 50V
C822 9965 000 40157 0.1μF 50V
C823 9965 000 40171 10μF 20% 16V
f
R101 9965 100 04841 27kΩ 5% 1/16-1/6W
R102 9965 000 40686 CFR 15kΩ 1/16W
R103 9965 000 40130 MOFR 27Ω
R105 9965 000 39984 CFR 75Ω 1/16W
R106 9965 000 39983 CFR 56Ω 1/16W
R107 9965 100 04838 180Ω 5% 1/16-1/6W
R109 9965 000 40304 CFR 1KΩ 1/16W
R111 9965 100 04849 680Ω 5% 1/16-1/6W
R113 9965 100 04838 180Ω 5% 1/16-1/6W
R117 9965 000 39975 CFR 100Ω 1/16W
R118 9965 000 39975 CFR 100Ω 1/16W
R150 9965 000 39975 CFR 100Ω 1/16W
R201 9965 000 39975 CFR 100Ω 1/16W
R202 9965 000 40695 CFR 3.3kΩ 1/16W
R203 9965 000 40695 CFR 3.3kΩ 1/16W
R204 9965 000 39975 CFR 100Ω 1/16W
R205 9965 000 40695 CFR 3.3kΩ 1/16W
R206 9965 000 39975 CFR 100Ω 1/16W
R208 9965 000 40686 CFR 15kΩ 1/16W
R210 9965 000 40700 CFR 4.7kΩ 1/16W
R214 9965 000 40122 MOFR 39kΩ
R215 9965 100 04849 680Ω 5% 1/16-1/6W
R216 9965 000 40695 CFR 3.3kΩ 1/16W
R217 9965 000 39975 CFR 100Ω 1/16W
R218 9965 000 39976 CFR 10kΩ 1/16W
R219 9965 000 39975 CFR 100Ω 1/16W
R220 9965 000 40695 CFR 3.3kΩ 1/16W
R221 9965 100 04846 47Ω 5% 1/16-1/6W
R222 9965 100 04839 2.2kΩ 5% 1/6W
R223 9965 100 04838 180Ω 5% 1/16-1/6W
R224 9965 000 40694 CFR 33Ω 1/16W
R228 9965 000 40304 CFR 1KΩ 1/16W
R229 9965 000 40687 CFR 1.8kΩ 1/16W
R230 9965 100 04836 1.2kΩ 5% 1/16-1/6W
R231 9965 100 04839 2.2k
Ω 5% 1/6W
R232 9965 000 39984 CFR 75Ω 1/16W
R234 9965 000 40695 CFR 3.3kΩ 1/16W
R235 9965 100 04839 2.2kΩ 5% 1/6W
R236 9965 000 39975 CFR 100Ω 1/16W
R237 9965 000 39975 CFR 100Ω 1/16W
R238 9965 000 40706 CFR 6.8kΩ 1/16W
R239 9965 000 39975 CFR 100Ω 1/16W
R240 9965 000 39975 CFR 100Ω 1/16W
R241 9965 000 39975 CFR 100Ω 1/16W
R242 9965 000 39976 CFR 10kΩ 1/16W
R243 9965 100 04841 27kΩ 5% 1/16-1/6W
R245 9965 000 40304 CFR 1KΩ 1/16W
R246 9965 000 40686 CFR 15kΩ 1/16W
R247 9965 000 40698 CFR 39kΩ 1/16W
R250 9965 100 04848 5.6kΩ 5% 1/16-1/6W
R251 9965 000 40304 CFR 1KΩ 1/16W
R252 9965 100 04841 27kΩ 5% 1/16-1/6W
R255 9965 000 40700 CFR 4.7kΩ 1/16W
R256 9965 000 40700 CFR 4.7kΩ 1/16W
R257 9965 000 39975 CFR 100Ω 1/16W
R258 9965 000 39975 CFR 100Ω 1/16W
R259 9965 000 39984 CFR 75Ω 1/16W
R260 9965 000 39975 CFR 100Ω 1/16W
R261 9965 000 39975 CFR 100Ω 1/16W
R301 9965 100 04864 0.33Ω 5% 2W
R302 9965 100 04864 0.33Ω 5% 2W
R304 9965 100 04856 220Ω 5% 1W
R305 9965 000 40687 CFR 1.8kΩ 1/16W
R306 9965 000 39985 CFR 5.6Ω
R307 9965 100 05312 0.82Ω 2W
R307A 9965 000 40524 NTC 5/5A
R307B 9965 100 07705 MOFR
R308 9965 000 40687 CFR 1.8kΩ 1/16W
R309 9965 100 05314 330Ω 2W
R310 9965 000 40702 CFR 470kΩ
1/16W
R311 9965 100 04841 27kΩ 5% 1/16-1/6W
R312 9965 000 40304 CFR 1KΩ 1/16W
R314 9965 000 40145 Fusible 0.18Ω 2W
R315 9965 100 07892 Fuse Resistor 3.3Ω 2W
R316 9965 000 40141 MOFR 3.3kΩ
R317 9965 100 04838 180Ω 5% 1/16-1/6W
R318 9965 100 04842 330Ω 5% 1/16-1/6W
R321 9965 100 04859 1kΩ 5% 2W
R322 9965 100 05313 1.5Ω 5% 2W
R323 9965 000 40701 CFR 47kΩ 1/16W
R324 9965 000 39975 CFR 100Ω 1/16W
R325 9965 000 40691 CFR 220Ω 1/16W
