29
b
Stereo audio output to headphones or
earphones.
c AUDIO L/R
Audio input from analogue devices
connected to VIDEO.
d VIDEO
Composite video input from analogue
devices such as VCRs.
e S-VIDEO
S-Video (side) to be used with Audio L/R
connectors for camcorder, game console,
etc. When you use the S-Video (side) for
video signals, do not use the Composite
video (side) input for video signals.
g SERV. U
For use by service personnel only.
Side connectors
a USB
Data input from USB storage devices.
1
2
6
3
4
5
English
EN
