Revision List
EN 2 TCM3.2L LA1.
2009-Jun-19
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
2. Technical Specifications and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connection Overview
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in Table 2-1.
Here is product information available, as well as getting started,
user manuals, frequently asked questions and software &
drivers.
Table 2-1 Described Model Numbers
2.2 Directions for Use
Click on the hyperlinks in table above.
2.3 Connection Overview
Figure 2-1 Rear and side I/O connections
CTN Styling Published in SM
32PFL5604/78
P & S
3122 785 18660
32PFL5604/77 3122 785 18660
42PFL5604/77
3122 785 18660
18530_001_090327.eps
090327
