Philips 48OLED935/12 - Page 126

9-6-21 DCDCd_+2V5
Vo u t =0 . 8* (1 + 42 . 6 /2 0 ) = 2 . 5
R4545
NC/100K 1/16W 5%
Q4505
LMUN5313DW1T1G
1 2 3 4
5 6
Q4504
AO3416
3
1
2
U4503
MP1471AGJ Z

GND
1
SW
2
IN
3
FB
4
EN
5
BST
6
L4503
3.3uH
C4539
NC/10uF 16V
R4537
100K
R4543
10K 5%
R4544
3.6K 1%
R4539
20K 1%
C4540
NC/1NF
R4546
39K 1%
C4542
100NF 16V
C4547
100NF 16V
C4541
1uF 16V
R4561
10K 5%
C4544
22UF 6.3V
R4540100R 5%
R4538
220K OHM
C4543
NC/22UF 6.3V
R454110R 5%
FB4504
120R 3A
1 2
ZD4502
MM3Z5V6B
C4545
10UF 16V
R4542
100K 1%
C4546
100NF 16V
C4538
22PF 50V
FRC_2.5V
PQ_3.3V
+3V3-NT
+12V
+2V5-NT
PQ_2.5V
PQ_2.5V
+12V
+ 2 V 5
