Philips 48OLED935/12 - Page 127

9-6-22 DCDCb_+1V5
Vo u t= 0 .8 * ( 1+ 3 3/ 3 6) = 1 .5 3 3
R4550
220K OHM
R4554
33K 1%
C4555
NC/1NF
R4558
91K 1%
C4558
47nF 16V
FB4505
120R 3A
1 2
R4549
47K
C4550
22PF 50V
C4549
10uf 16V
R4552
220K OHM
R4560100R 5%
U4504
MP1471AGJ Z

GND
1
SW
2
IN
3
FB
4
EN
5
BST
6
R4556
0R05
C4559
47nF 16V
R4532
NC/0R05 1/10W
R4553
10K 5%
C4551
100NF 16V
C4548
NC/10uF 16V
C4554
22uF 6.3V
R4559
NC/100K 1/16W 5%
C4556
100NF 16V
R4547
100K
R4548
100K
Q4506
AO3416
3
1
2
R4555
36K 1%
ZD4504
MM3Z5V6B
Q4507
LMUN5313DW1T1G
1 2 3 4
5 6
C4557
100NF 16V
C4552
22UF 6.3V
Q4508
AO3416
3
1
2
R4551
68K
ZD4503
MM3Z5V6B
L4504
3.3uH
R455710R 5%
Q4509
LMUN5313DW1T1G
1 2 3 4
5 6
DDR_1.5V
+12V
DDR_1.5V
FRC_1.5V
+3V3-NT
+1V5-NT
+12V
PQ_1.5V
+12V
DDR_1.5V
+1V5-NT
PQ_3.3V
PQ_2.5V
DD R _ 1 . 5 V
C4553
1uF 16V
NT 7 2 3 1 5 PQ _ 1 . 5 V
Enable by PQ_2.5V
NT 7 2 3 3 4 + 1 . 5 V - N T
Enable by +3V3-NT
