Philips 48OLED935/12 - 715 G8131 Ssb

9.5 B 715G8131M SSB( For 48”/55”65” OLED935 Series)
9-5-1 DCDCa_+1V0_+0V9
R4127
NC/10 OHM 1/16W
R4108
100 OHM
R4120
200K 1%
C4111
22uF 6.3V
R4124
100K 1%
R4114
270K 1%
R4123
39K 1%
C4113
NC/22UF 6.3V
C4108
0.22UF 25V
C4130
22uF 6.3V
R4134
0R05
C4125
NC/22UF 6.3V
R4115
100K 1%
C4101
NC/10uF 16V
R4122
NC/470K 1/16W 5%
R4105
NC/470K 1/16W 5%
R4132
0R05
R4113
39K 1%
C4133
NC/10uF 16V
C4137
33PF 50V
U4102
MP2329GG-Z
SW
6
BST
7
PGND
4
IN
1
FB
10
PG
5
AGND
9
EN
11
VCC
8
PGND
3
PGND
2
C4110
22uF 6.3V
C4112
22uF 6.3V
C4128
22uF 6.3V
C4103
100NF 16V
C4102
NC/10uF 16V
C4121
0.22UF 25V
R4133
NC/10 OHM 1/16W
C4120
1uF 10V
C4132
10uf 16V
L4102
0.68uH
U4101
MP2329GG-Z
SW
6
BST
7
PGND
4
IN
1
FB
10
PG
5
AGND
9
EN
11
VCC
8
PGND
3
PGND
2
C4100
10uf 16V
R4135
150K 5%
C4107
1uF 6.3V
C4136
33PF 50V
R4136
100K
L4100
0.68uH
C4134
100NF 16V
C4129
22uF 6.3V
FB4101
120R 3A
12
R4128
100K
R4118
100 OHM
FB4100
120R 3A
12
C4131
NC/10uF 16V
+12V
R4106
100K
+12V
VCC1
FRC_0.9V+0V9-NT
SENSE+0V9-NT 14
BE-PWR-EN6,12
VCC2
VCC1
+0V9-NT-EN
VCC2
+3V3-ENABLE
+0V9-NT-EN
NT7 2 3 34 + 0 V 9 - N T
+1V0-FPGA
SENSE+1V0-FPGA 7
FP G A + 1 V 0 - FP G A
+3V3-ENABLE 4
+3V3-ENABLE
