Philips 48OLED935/12 - Page 93

9-5-2 DCDCb_+1V5_+1V2_+5V
FB4201
120R 3A
1 2
FB4202
120R 3A
1 2
FB4203
120R 3A
1 2
Upd a t e d o n 20 2 0/ 2/ 7
Upd a t e d o n 2 0 2 0 / 2/ 7
R4200
NC/100K 1/16W 5%
U4201
MP1471AGJ Z

GND
1
SW
2
IN
3
FB
4
EN
5
BST
6
C4207
NC/10uF 16V
L4200
3.3uH
R4208
10K 5%
R4204
36K 1%
R4201
0.05R
R4202
33K 1%
C4209
100NF 16V
C4212
NC/1NF
C4202
22UF 6.3V
C4211
1uF 16V
C4203
NC/22UF 6.3V
R4203100R 5%
FB4200
120R 3A
1 2
R421210R 5%
C4208
10uF 16V
C4210
22PF 50V
+12V
+3V3
R4220
NC/100K 1/16W 5%
U4203
SY8104IADC
LX
5
FB
1
EN
2
GND
3
IN
4
BS
6
C4243
NC/10uF 16V
L4202
2.2uH
R4213
10K 5%
R4221
10K 1%
R4223
470R 1%
R4218
15K 1%
C4226
100NF 16V
C4245
NC/1NF
C4237
22UF 6.3V
C4241
100NF 16V
C4238
NC/22UF 6.3V
R4222100R 5%
FB4205
120R 3A
1 2
C4244
10uF 16V
+12V
C4248
220PF 50V
+3V3
R4209 22K
R4207
5.6K 1%
R4210
68K 1%
R4206
10K 5%
C4218
10uF 6.3V
C4219
1nF 50V
C4215
10uF 6.3V
+3V3
+1 V 2 - M G T F r o m + 1 V5 - F P G A
C4240
10uF 6.3V
U4200
G9661-25ADJF11U
POK
1
VEN
2
VIN
3
VPP
4
NC
5
VO
6
ADJ
7
GND
8
E-Pad
9
R4211
10K 1%
+1 V 5 - NT
C4216
10uF 6.3V
+ 1 V 2 - M G T
+1V2-MGT
R4205
91K 1%
+1V5-NT
+1V5-FPGA
+1 V5 - F P G A
+1V5-FPGA
SENSE+1V2-MGT 7
R4338
10K 5%
0. 7 6 5 x ( 1 +5 6 . 1 / 1 0 ) = 5 . 0 5 V
+ 5 V f or L DM
R4336
10K 1%
C4325
100NF 16V
C4322
22uF 6.3V
R4334
5.1K 1%
R4337
15K OHM
U4204
RT6253AHGJ6F
GND
1
SW
2
VIN
3
FB
4
EN
5
BOOT
6
L4302
3.3uH
C4323
100NF 16V
C4327
100NF 16V
C4321
10PF 50V
C4326
10uF 16V
C4328
100NF 16V
R4335
51K 1%
+12V
+5V-SW
