Whitepoint alignment
Customise the whitepoint alignment based on the
selected colour temperature of the picture. Press the
arrows (up) or (down) to adjust the value,
press Reset to reset the value.
Contrast Settings
Contrast Modes
(Home) > Settings > All
settings > Picture > Expert mode
settings > Contrast
mode
Select Normal, Optimized for picture, Optimized for
energy saving to set the TV automatically reduces
the contrast, for best power consumption or for best
picture experience, or select Off to switch off the
adjustment.
HDR Plus
(Home) > Settings > All
settings > Picture > Expert mode settings > HDR
Plus
Set HDR Plus to Off, Minimum, Medium,
Maximum or Automatic to set the level at which the
TV automatically shows superior contrast and
brightness effect for HDR content.
Note: Available when HDR (High-Dynamic Range)
signal is detected.
• The TV can play HDR programmes from any one of
HDMI connections, broadcasting, from an Internet
source (e.g. Netflix) or from a connected USB memory
device.
• The TV will automatically switched to HDR mode
with indication. TV supports following HDR formats:
Hybrid Log Gamma, HDR10, HDR10+, and Dolby
Vision but it is subject to the availability of such HDR
format in content providers.
Dynamic Contrast
(Home) > Settings > All
settings > Picture > Expert mode
settings > Dynamic contrast
Select Maximum, Medium, or Minimum to set the
level at which the TV automatically enhances the
details in the dark, middle and light areas of the
picture.
Video Contrast, Gamma
Video contrast
(Home) > Settings > All
settings > Picture > Expert mode settings > Video
contrast
Press the arrows (up) or (down) to adjust the
video contrast level.
Gamma
(Home) > Settings > All
settings > Picture > Expert mode
settings > Gamma
Press the arrows (up) or (down) to set a non-
linear setting for picture luminance and contrast.
Ultra Resolution
(Home) > Settings > All
settings > Picture > Expert mode settings > Ultra
resolution
Select On to have a superior sharpness in line
edges and details.
Picture Clean
Noise reduction
(Home) > Settings > All
settings > Picture > Expert mode settings > Noise
reduction
Select Maximum, Medium, Minimum to set the
level for removing the noise in video content.
Noise is mostly visible as small moving dots in on-
screen picture.
MPEG Artefact Reduction
(Home) > Settings > All
settings > Picture > Expert mode
settings > MPEG Artefact Reduction
Select Maximum, Medium, Minimum to have
different degress of smoothing the artefects in digital
video content.
MPEG artefacts are mostly visible as small blocks or
jagged edges in on-screen images.
Motion Settings
Motion Styles
(Home) > Settings > All
settings > Picture > Expert mode
34

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PUS6704 and is the answer not in the manual?

Philips 55PUS6704 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Zoom capabilityYes
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Native refresh rate60 Hz
Display diagonal (metric)139 cm
Supported graphics resolutions3840 x 2160
Motion interpolation technology-
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.3 W
Power consumption (typical)85 W
Product colorBlack
Panel mounting interface300 x 200 mm
Package typeBox
Package depth160 mm
Package width1360 mm
Package height860 mm
Package weight20500 g
PC in (D-Sub)No
HDMI ports quantity3
USB 2.0 ports quantity2
Digital audio optical out1
Consumer Electronics Control (CEC)EasyLink
Programming period8 day(s)
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2, DVB-T2 HD
Video appsYouTube
Audio decodersDolby Atmos
RMS rated power20 W
Equalizer bands quantity5
Wi-Fi standardsWi-Fi 4 (802.11n)
Processor cores4
Audio formats supportedAAC, HAAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, HEIF, JPEG, PNG
Video compression formatsAVC, AVI, H.264, H.265, MKV, MPEG1, MPEG2, VP9, WMV9
Subtitle formats supportedASS, SMI, SRT, SUB, TXT
High Dynamic Range (HDR) technologyHigh Dynamic Range (HDR) 1500, High Dynamic Range 10+ (HDR10 Plus)
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Stand width790 mm
Stand height18.4 mm
Depth (with stand)235.4 mm
Height (with stand)742 mm
Weight (with stand)16400 g
Depth (without stand)79.9 mm
Width (without stand)1236.6 mm
Height (without stand)723.6 mm
Weight (without stand)16100 g
