Philips 55PUS6704 User Manual

21
Specifications
21.1
Power
Product specifications are subject to change without
notice. For more specification details of this product,
see www.philips.com/TVsupport
Power
• Mains power : AC 220-240V +/-10%
• Ambient temperature : 5°C to 35°C
For power consumption information, see
chapter Product Fiche.
21.2
Reception
• Aerial input : 75 ohm coaxial (IEC75)
• Tuner bands : Hyperband, S-Channel, UHF, VHF
• DVB : DVB-T2, DVB-C (cable) QAM
• Analogue video playback : SECAM, PAL
• Digital video playback : MPEG2 SD/HD (ISO/IEC
13818-2), MPEG4 SD/HD (ISO/IEC 14496-10), HEVC*
• Digital audio playback (ISO/IEC 13818-3)
• Satellite aerial input : 75 ohm F-type
• Input frequency range : 950 to 2150MHz
• Input level range : 25 to 65 dBm
• DVB-S/S2 QPSK, symbol rate 2 to 45M symbols,
SCPC and MCPC
• LNB : DiSEqC 1.0, 1 to 4 LNBs supported, Polarity
selection 14/18V, Band selection 22kHz, Tone burst
mode, LNB current 300mA max
* Only for DVB-T2, DVB-S2
21.3
Display Resolution
Diagonal screen size
• 43PUS6704 : 108 cm / 43 inch
• 50PUS6704 : 126 cm / 50 inch
• 55PUS6704 : 139 cm / 55 inch
• 65PUS6704 : 164 cm / 65 inch
• 70PUS6704 : 176 cm / 70 inch
Display resolution
• 3840 x 2160
21.4
Supported Input Resolution -
Video
Support Timing
Video support timing also includes field/frame rate
23.976Hz, 29.97Hz and 59.94Hz.
HDMI
• 480i
• 480p
• 576i
• 576p
• 720p
• 1080i
• 1080p
• 3840 x 2160p - 24Hz, 25Hz, 30Hz, 50Hz, 60Hz
HDMI - UHD
 (Home) > Settings > General settings > Input
sources > HDMI (port) > HDMI Ultra HD
This TV can display Ultra HD signals. Some devices -
connected with HDMI - do not recognise a TV with
Ultra HD and might not work correctly or show
distorted picture or sound.
To avoid the malfunctioning of such a device, you can
set the signal quality to a level the device can handle.
If the device is not using Ultra HD signals, you can
switch off Ultra HD for this HDMI connection.
• The setting Optimal allows maximum up to Ultra HD
(50Hz or 60Hz) RGB 4:4:4 or YCbCr 4:4:4/4:2:2/4:2:0
signals.
• The setting Standard allows maximum up to Ultra
HD (50Hz or 60Hz) YCbCr 4:2:0 signals.
Component, Composite
Composite
• PAL, NTSC, SECAM
Component
• 480i
• 480p
• 576i
• 576p
• 720p - 50Hz, 60Hz
• 1080i - 50Hz, 60Hz
• 1080p - 50Hz, 60Hz
55

Philips 55PUS6704 Specifications

General

Screen shape	Flat
Response time	- ms
Zoom capability	Yes
Display diagonal	55 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
Display diagonal (metric)	139 cm
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	-
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.3 W
Power consumption (typical)	85 W
Product color	Black
Panel mounting interface	300 x 200 mm
Package type	Box
Package depth	160 mm
Package width	1360 mm
Package height	860 mm
Package weight	20500 g
PC in (D-Sub)	No
HDMI ports quantity	3
USB 2.0 ports quantity	2
Digital audio optical out	1
Consumer Electronics Control (CEC)	EasyLink
Programming period	8 day(s)
Firmware upgradeable via	Auto upgrade wizard, Network, USB
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2, DVB-T2 HD
Video apps	YouTube
Audio decoders	Dolby Atmos
RMS rated power	20 W
Equalizer bands quantity	5
Wi-Fi standards	Wi-Fi 4 (802.11n)
Processor cores	4
Audio formats supported	AAC, HAAC, MP3, WAV, WMA, WMA-PRO
Image formats supported	BMP, GIF, HEIF, JPEG, PNG
Video compression formats	AVC, AVI, H.264, H.265, MKV, MPEG1, MPEG2, VP9, WMV9
Subtitle formats supported	ASS, SMI, SRT, SUB, TXT
High Dynamic Range (HDR) technology	High Dynamic Range (HDR) 1500, High Dynamic Range 10+ (HDR10 Plus)
Cables included	AC

Weight and Dimensions

Stand width	790 mm
Stand height	18.4 mm
Depth (with stand)	235.4 mm
Height (with stand)	742 mm
Weight (with stand)	16400 g
Depth (without stand)	79.9 mm
Width (without stand)	1236.6 mm
Height (without stand)	723.6 mm
Weight (without stand)	16100 g
